CONTROLLER 48/60-35 AMP WIRE

CONTROLLER 48/60-35 AMP WIRE Specification

Model No
48/60-35 AMP WIRE

Part Type
Wired Controller

Dimension (L*W*H)
195 mm x 90 mm x 55 mm

Power Type
DC

Weight
Approx. 1.5 kg

Mounting
Chassis Surface Mount

Finish
Matte

Color
Silver

Usage & Applications
Electric Vehicle Speed & Power Control

Voltage
48V/60V

Product Type
Controller

Type
48/60-35 Amp Wire

Material
Aluminium Alloy & Electronic Components

Vehicle Type
Electric Vehicle (E-Rickshaw, E-Bike, E-Scooter)

Display Compatibility
Supports Digital and Analog Display Meters

Enclosure Type
IP54-rated for dust and water resistance

Operating Temperature
-20°C to 55°C

Control Mode
Sine Wave Controller

Input Voltage Range
48V-60V DC

Drive Mode
Forward/Reverse/Both

Throttle Type Support
Analog & Digital Throttle

Protection Features
Overcurrent, Overvoltage, Short Circuit Protection

Connectors
Multi-pin Wire Harness

Wire Length
Standard: 50 cm

Wire Type
High Quality Copper Cables

Max Output Current
35A

Compatibility
BLDC Motor (Brushed/Brushless Motors Supported)

About CONTROLLER 48/60-35 AMP WIRE

For a controller rated at 48V/60A, the wire gauge selection is crucial to ensure safe and efficient operation. The wire gauge should be chosen based on the current rating and the length of the wire run to minimize voltage drop and prevent overheating.

Robust Power and Versatility

This sine wave controller supports both 48V and 60V DC systems with up to 35A output current, making it adaptable to a variety of electric vehicles. Its compatibility with both brushed and brushless BLDC motors ensures maximum application flexibility, while support for multiple throttle and display types enhances user convenience.

Reliable Protection and Performance

Equipped with built-in mechanisms for overcurrent, overvoltage, and short-circuit protection, the controller safeguards both the vehicle and user. The IP54-rated aluminium alloy enclosure delivers solid environmental resistance, ensuring lasting performance even under demanding conditions.

Effortless Integration and Installation

Featuring a standard 50 cm, high-quality copper wire harness and chassis surface mounting design, installation is straightforward. The multi-pin connectors enable quick connection to different vehicle systems, minimizing setup time and enhancing reliability for manufacturers and users alike.

FAQ's of CONTROLLER 48/60-35 AMP WIRE:

Q: How does the CONTROLLER 48/60-35 AMP WIRE enhance electric vehicle performance?

A: By delivering a stable and efficient power output of up to 35A and supporting both brushed and brushless BLDC motors, this controller ensures smooth acceleration, responsive speed regulation, and reliable operation for various electric vehicles.

Q: What protection features does this controller offer during operation?

A: The controller integrates overcurrent, overvoltage, and short-circuit protection to safeguard internal electronics, motors, and vehicle occupants from electrical faults, ensuring secure and safe usage.

Q: When and where should this controller be installed in an electric vehicle?

A: Install the controller on the chassis surface, as recommended, using the included mounting provisions. Its compact and IP54-rated enclosure allows for use in dust- and water-prone environments, suitable for e-rickshaws, e-bikes, and e-scooters.

Q: What is the process for connecting the multi-pin wire harness to the motor and throttle?

A: With clearly labeled high-quality copper wires and multi-pin connectors, you simply align and attach the respective cables to the motor, throttle (analog or digital), and display meter. Ensure that connections are secure and follow the wiring diagram provided by the manufacturer.

Q: Which display meters and throttle types are compatible with this controller?

A: The controller is designed to support both digital and analog display meters, as well as analog and digital throttle types, offering flexibility in dashboard integration and control preferences.

Q: What are the primary benefits of using the sine wave controller mode in this product?

A: Sine wave control delivers smoother and quieter motor operation, improved efficiency, reduced motor heating, and more precise speed control, thereby enhancing the driving experience and increasing the overall lifespan of the motor.
