MALE SOCKET 3 PIN OPT

MALE SOCKET 3 PIN OPT Specification

Weight
Approx. 25 grams

Part Type
Socket Connector

Dimension (L*W*H)
35mm x 18mm x 12mm

Voltage
12V / 24V (Compatible)

Usage & Applications
Used for making secure electrical connections in wiring harnesses and panels

Mounting
Panel Mount or Free-hanging

Color
Black

Power Type
AC/DC

Model No
OPT-3P-MS

Finish
Matte

Product Type
Male Socket 3 Pin OPT

Type
Electrical Connector

Material
High-Grade Plastic and Metal Contacts

Vehicle Type
Automotive, Commercial Vehicles, Industrial Applications

Operating Temperature
-25C to +85C

IP Rating
IP44 (Splash resistant)

Wire Gauge Compatibility
Up to 2.5mm

Flammability Class
UL94 V-0

Current Rating
Up to 10A

Compliance
RoHS Compliant

Number of Pins
3

Contact Material
Brass with Nickel Plating

Insulation Resistance
>1000 M

Connector Gender
Male

About MALE SOCKET 3 PIN OPT

A "Male Socket 3 Pin OPT" refers to a male electrical connector with three pins that may include optional (OPT) features or configurations. These connectors are commonly used in various electrical and electronic applications to establish secure and reliable connections.

Rugged and Reliable Electrical Connectivity

Engineered for durability, the MALE SOCKET 3 PIN OPT blends brass core contacts with a nickel finish to guarantee secure electrical performance over time. It supports demanding environments and frequent usage cycles, providing peace of mind for automotive and industrial operators.

Versatile Mounting and Broad Compatibility

Installation is straightforward with flexible mounting options-choose panel mount for permanent setups or free-hanging for adaptable applications. Compatible with both AC and DC power up to 10A, this socket suits various wiring harnesses in vehicles and industrial panels alike.

FAQ's of MALE SOCKET 3 PIN OPT:

Q: How can the MALE SOCKET 3 PIN OPT be installed in a wiring system?

A: The male socket can be panel-mounted for permanent, robust connections or used as a free-hanging connector for more flexible setups. Its dimensions (35mm x 18mm x 12mm) allow easy integration into automotive and industrial wiring harnesses.

Q: What are the main benefits of using this 3-pin connector for electrical applications?

A: Benefits include secure signal and power transmission, high insulation resistance (>1000 M), splash-resistant IP44 protection, and compatibility with both AC and DC systems. Its nickel-plated brass contacts and UL94 V-0 rated housing further enhance safety and longevity.

Q: When should I choose this socket for my project?

A: This product is ideal when you require safe, reliable connections for wiring harnesses or control panels in automotive, commercial vehicle, or industrial contexts, especially when splash resistance and RoHS compliance are crucial.

Q: Where is this socket most commonly utilized?

A: It is widely used in vehicle wiring systems, commercial vehicle panels, and various industrial applications where secure, multi-pin connections are essential. Exporters, manufacturers, and suppliers across India choose this connector for quality and versatility.

Q: What process is recommended for connecting wires to the socket?

A: Stripped wires (up to 2.5mm2) should be properly secured to the connector's terminals, ensuring a tight fit for optimal conductivity. Follow standard panel-mounting procedures if installing into a fixed enclosure.

Q: How does the socket ensure safety and regulatory compliance?

A: With a UL94 V-0 flammability rating, RoHS compliance, and a robust insulation resistance, this socket excels in both fire safety and environmental standards. Its high-grade materials and IP44 rating further reinforce overall protection during use.
